SNE‑ES F16 – Powerful LiFePO₄ battery storage for safe and efficient energy storage
Perfect for those who want to store energy in:
Summer cottage, mountain cabin or archipelago house
Fishing shed, pier or coastal off‑grid environments
Home business, agriculture or commercial premises
Industry, production or technical spaces
Off‑grid systems, backup power and larger solar installations
The SNE‑ES F16 is a premium battery storage system built on safe and long-lasting LiFePO₄ technology, perfect for both commercial and advanced residential energy systems. With 16.38 kWh nominal energy capacity, high efficiency and robust construction, this battery delivers stable and reliable operation – even in demanding environments.
This is a battery pack for those who want maximum performance, security and flexibility in their energy storage.
Key Features & Benefits
🔋 High energy capacity
Nominal energy: 16.38 kWh
Useable energy: 14.75 kWh
Perfect for solar power systems, backup power, industrial applications or larger off-grid installations.
⚡ Powerful output
Peak power (10 sec): 15.36 kW
Maximum charge/discharge: 200 A / 200 A
Provides stable energy even at high loads.
🌱 Maximum efficiency and lifespan
Round-trip efficiency: ≥97.5%
Cycle life: >6,000 cycles (at 25 °C)
Designed lifespan: 20+ years
The LiFePO₄ cells provide high safety, low heat generation and a very long lifespan.
🧠 Smart communication
Support for CAN and RS485
Simple and flexible integration with inverters and control systems.
🛡️ Robust construction
Protection class: IP21
Operating temperature from –20 to +60 °C
Passive, natural cooling for quiet and maintenance-free operation.
⚙️ Modular and scalable
Up to 16 battery units in parallel connection
Perfect for system expansion up to large-scale installations.
🏚️ Flexible installation
Freestanding, for indoor use
Easy and quick installation in rack rooms, technical rooms or power centers.
Technical specifications
Property Value
Battery type 51.2 V 320 Ah LiFePO₄
Nominal energy 16.384 kWh
Useable energy 14.75 kWh
Nominal voltage 51.2 V
Operating voltage 44–58.4 V
Max charge/discharge 200 A / 200 A
Efficiency ≥97.5%
Communication CAN, RS485
Cooling Passive (natural cooling)
Protection class IP21
Operating temperature –20 to +60 °C
Recommended DOD 90%
Dimensions (W × D × H) 573 × 981 × 1168 mm
Weight 130 kg
Humidity 5–95%
Altitude < 2,000 m
Scalability Max 16 units in parallel
Warranty 5 years
Safety standard UL1973 / IEC62619 / UN38.3
Summary
The SNE‑ES F16 is a powerful, reliable and future-proof energy storage solution that combines high capacity, advanced safety and long service life. Perfect for those who want to optimize energy consumption, increase their own use of solar energy or secure operation during power outages.
Combines well with our mini wind turbines or your choice of solar cells.
